E.4) SERVOMOTOR OUTPUT
Fig. 15 SERVOMOTOR OUTPUT WIRING
Switching mode: isolated zero crossing type.
Rated current: from 50 mA to 1 A.
Rated voltage: from 24 V
RMS
to 240 V
RMS
-10 % +15 % (50/
60Hz)
Load type: resistive load only
NOTES 1) To avoid electrical shock, connect power line at
the end of the wiring procedure.
2) For power connections use No 16 AWG or larger
wires rated for at last 75 °C.
3) Use copper conductors only.
4) Don’t run input wires together with power cables.
5) This output is not fuse protected. Please, provide it
externally using a fuse with a I
2
t equal to128.
29
30
31
Servo-
motor
Power
line
12
13
14
s (Open the valve)
t (Close the valve)
Feedback
potentiometer
Shield
s (Open)
t (Close)
