ero electronic MKC - On the Main Input; Overrange, Underrange and Sensor Leads Break Detection; Error Messages

102
Gr.Hd
- Hidden group default data loading - [r.L06]
Range: OFF = No loading data
On = loading data
ERROR MESSAGES
OVERRANGE, UNDERRANGE AND SENSOR LEADS
BREAK DETECTION
ON THE MAIN INPUT
The device is capable to detect a fault condition on the main
input (OVERRANGE or UNDERRANGE or SENSOR LEADS
BREAK).
When the process variable exceeds the full scale value
programmed by "ñ.In.t" [C.d02], an OVERRANGE condition will
be shown on the upper display as show in the following figure:
When the process variable is lower than the initial scale value
programmed by "ñ.In.t" [C.d02], an UNDERRANGE condition
will be shown on the upper display as show in the following
figure:
