28
t = o During parameter modification, it allows you to
decrease the value of the selected parameter
o During MANUAL mode, it allows to decrease the
output value.
RSP = allows to toggle from Local set point to Remote set
point or viceversa when depressed for more than 1
sec.
t+MENU= are used to start the lamp test function (the
command is accepted when push-button are kept
depressed for more than 5 s and device is in normal
display mode)
s+FUNC or t+FUNC
During parameter modification they allow you to
increase/decrease the value under modification with
higher rate.
s+MAN or t+MAN
During parameter modification they allow you to
jump to the max or min programmable value.
NOTES:
1) All the actions explained above which requires two or more
push-buttons must follow exactly the push-button sequence
shown.
2) A 10 or 30 seconds time out (see "t.out" [C.I10]) can be
selected for parameter modification during run time mode.
If, during parameter modification, no push-button is
depressed for more than 10 (30) seconds, the instrument
goes automatically to the “normal display mode” and the
eventual modification of the last parameter will be lost.
