A. 2
The following is a list of the default run time parameters loaded
during the above procedure:
Run time group 1 [r.Axx]
PARAMETER DEFAULT VALUE
SP = Set point low limit ("rL" [r.E12])
SP2 = Set point low limit ("rL" [r.E12])
SP3 = Set point low limit ("rL" [r.E12])
SP4 = Set point low limit ("rL" [r.E12])
Run time group 3 [r.Cxx]
PARAMETER DEFAULT VALUE
ñ.rSt = OFF
AL1 = Initial range value (for process alarm)
= 0 (for deviation alarm)
= 0.0 (for control output alarm)
bA1.L = 0
bA1.h = 0
AL2 = Initial range value (for process alarm)
= 0 (for deviation alarm)
= 0.0 (for control output alarm)
bA2.L = 0
bA2.h = 0
AL3 = Initial range value (for process alarm)
= 0 (for deviation alarm)
= 0.0 (for control output alarm)
bA3.L = 0
bA3.h = 0
AL4 = Initial range value (for process alarm)
= 0 (for deviation alarm)
= 0.0 (for control output alarm)
bA4.L = 0
bA4.h = 0
A.L.Fd = Initial scale value
A.H.Fd = Final scale value
HSA1 = 1
HSA2 = 1
HSA3 = 1
HSA4 = 1
Run time group 4 [r.dxx]
PARAMETER DEFAULT VALUE
Pb = 4.0 %
HYS = 0.5 %
ti = 4.00 mm.ss
td = 1.00 mm.ss
IP = 50.0 (If only one control output is configured).
0.0 (If two control outputs, without split
range, are configured).
