67
b) push the FUNC push-button; the lower display will show " A."
followed by the current consumed by the load under test
when the load is in ON condition (see also "OUT failure
detection").
c) Push FUNC push-button again, the lower display will show "
b." followed by the leakage current running in the load under
test when the load is in OFF condition (see also "OUT failure
detection").
d) Push FUNC push-button again, the lower display will show "
Fd." followed by the OUT failure detection alarm status:
OF = no alarm
AL (flashing) = alarm
AL (steady) = acknowledged alarm
e) Push FUNC push-button again, the lower display will show "
ñ." followed by the MAIN control output value in the range 0.0
% (-19.0 % for feedback) to 99.9 % (“ . “ shows that the
control output is > 100.0 %) or within the scale configured by
“ñC.E.L” [C.F09] and “ñC.E.H” [C.F10].
NOTE: When the MAIN output is a servomotor type, the
instrument shows, for this output, the feedback position
instead of the output in percent.
f) Push FUNC push-button again, the lower display will show "
S." followed by the SECONDARY control output value in the
range 0.0 % (-19.0 % for feedback) to 99.9 %
(“ . “ shows that the control output is > 100.0 %) or
within the scale configured by “SC.E.L” [C.F15] and “SC.E.H”
[C.F16].
NOTE: When the secondary output is a servomotor type, the
instrument shows, for this output, the feedback position
instead of the output in percent.
g) Push FUNC push-button again, the lower display will show
the value of the auxiliary input, if configured.
- Pushing FUNC push-button again, the display will come back
to the control output value indication.
All the seven types of visualization are not bound to a time out
unless OFD (output failure detection) is in not acknowledged
alarm condition.
In this situation, the instrument forces the indication described at
point d) and, if a different indication is required, it restores this
indication after time out (see “t.out” [C.I10]).
