76
Gr.2
- Set point 3 - [r.A03]
This parameter is available only when one of the logic inputs is
configured for SP3/SP4 selection.
Range: from "rL" [r.E12] to "rH" [r.E13].
- Set point 4 - [r.A04]
This parameter is available only when one of the logic inputs is
configured for SP/SP2 selection and another one for SP3/SP4
selection.
Range: from "rL" [r.E12] to "rH" [r.E13].
- Group 1 default data loading - [r.A05]
Range: OFF = No loading data
ON = Loading data
Run time group 2 [r.bxx]
SMART ENABLE/DISABLE
- SMART function - [r.b01]
This parameter is available when at least one control output is
configured and SMART function is enabled (“Sñ.Fn” [C.G01]=
“Enb”)
Range: OFF = SMART algorithm is deactivated
ON = SMART algorithm is activated
Set On or OFF to activate/deactivate the SMART algorithm.
Xkc-1-C0.P65 5/29/02, 11:59 AM76
