2.2.11. 7700FR-DQ FRAME

The 7700FR-DQ frame provides up to 360W per power supply. The frame utilizes side venting for

improved air-flow through the frame, resulting in the use of lower air-flow fans which perform with a

quieter operation. The 7700FR-DQ frame is recommended to be used in installs where noise is of

concern.

The 7767VIPX modules must be installed in the 7700FR-D or DQ frame.
