6.1.4. Serial Video Output
Standard: Selectable HD/SD serial monitoring output (720p, 1080i, 625i, 525i)
Number of Outputs: 2
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 200ps nominal (HD), 740ps nominal (SD)
Overshoot: < 10% of amplitude
6.1.5. Genlock Input
Type: NTSC/PAL colour black
Level: 1V p-p nominal
Connector: BNC via 7700FR-D (frame genlock)
6.1.6. General Purpose Interface I/O (GPI/GPO)
Number of Inputs: 4 (pins 10,11,12,13)
Number of Outputs: 2 (pins 4,9)
Type: GPI: 1 Opto-isolated, active low with internal pull-ups to +5V
GPO: 1 Relay closure to ground
Input Signal: Closure to ground
Connector: HD-15
6.1.7. Input/Output Serial Port
Number of Ports: 1 RS-232 (pins 6, 7) or 1 RS-422 (pins 1, 2, 6, 7)
Connector: HD-15
Baud Rate: Up to 1Mbaud
Format: Image Video, TSL
6.1.8. Ethernet
Network Type: Fast Ethernet 100 Base-TX 1EEE 802.3U standard for 100Mbps base band
CSMA/CD local area network
Connector: RJ-45 x2
6.1.9. Electrical
Voltage: +12V DC
Power: 75W
6.1.10. Physical
Number of Slots: 5 slots (single module occupies only ½ of total rear plate)
