5. Select (4) Under Monitor Display Setup from the main menu to set up the display card for Image
Video protocol operation.
------------------------------------------------
| Under Monitor Display Setup |
| (7767VIPX8x2 1.0.0) |
------------------------------------------------
------------------------------------------------
Protocol: Image Video
Input Type: serial
------------------------------------------------
(1) Set protocol
(S) Save and Exit
(X) Exit
>
Figure 11-2: Under Monitor Display Setup
6. Wire the serial connection from the router/switcher to the auxiliary serial port of the VIPX.
7. Power-cycle the VIPX frame.
8. Using Maestro, add a UMD to a video object by dragging and dropping it onto the video object.
9. In Mode Settings > Mode > Function, select Protocol ID from the drop-down box.
10. Set the Active Protocol ID to match the video mapping defined by the router/switcher.
When the VIPX receives a command from the router/switcher it will now be displayed on the output
display.
11.2. SETTING UP VIPX TO WORK WITH TSL PROTOCOL
1. Select RS-422 serial operation by setting jumpers J33 and J34 to this position on the auxiliary
daughter card on the display card.
2. Power up the system.
3. Set up the auxiliary (rear) serial port baud rate to match the router/switcher device.
This is performed via the upgrade serial port on the front of the card.
4. Select (5) Auxiliary Serial Port Setup from the main menu of the terminal program.
