evertz VIP-X - ASCII Protocol Setup

VIP-X System Manual
Revision 1.0 VIP-X - 69
When the VIPX receives a command from the router/switcher it will now be displayed on the output
display.
The command that the user expects to see is as follows:
S:02,0 = 02: level 0, destination 2
= ,1: source 1
Figure 11-9: Command Displayed on the Output Display
Therefore, using the above files as an example – the user will display at UMD protocol ID 1, the text
string “name 2”.
11.4. SETTING UP VIPX TO WORK WITH ASCII PROTOCOL
11.4.1. Creating the Text File
1. Create a text file named “router.cfg” and save it to the compact flash on the display card.
Use the following example to setup the file:
# Input id
String
0 Source 0
1 Source 1
2 Source 2
3 Evertz VIP-X
Figure 11-10: Input ID and String
Example:
0 Source0
1 Source1
2 Source2
3 Evertz VIP-X
2. FTP the file to the compact flash cards of all display cards in the system:
C:\ftp “IP address of display card”
ftp>put router.cfg
ftp>quit
