router_dst.cfg
# umd protocol id
dst id
0 1
1 2
2 3
Figure 11-6: Sample Text Files
Example:
Sample
router_dst.cfg file:
0 1
1 2
2 3
2. FTP both files to the compact flash cards of all display cards in the system:
C:\ftp “ip address of display card”
ftp>put router_src.cfg
ftp>put router_dst.cfg
ftp>quit
11.3.2. Setting Up the Display Card(s)
1. Select either RS-422 or RS-232 serial operation by setting jumpers J33 and J34 to one of these two
positions on the auxiliary daughter card of the display card.
2. Power up the system.
3. Set up the auxiliary (rear) serial port baud rate to match the router/switcher device.
4. This is performed via the upgrade serial port on the front of the card.
5. Select (5) Auxiliary Serial Port Setup from the main menu of the terminal program.
