VIP-X System Manual
VIP-X - 70 Revision 1.0
11.4.2. Setting Up the Display Card(s)
1. Select either RS-422 or RS-232 serial operation by setting jumpers J33 and J34 to one of these two
positions on the auxiliary daughter card of the display card.
2. Power up the system.
3. Set up the auxiliary (rear) serial port baud rate to match the router/switcher device.
This is performed via the upgrade serial port on the front of the card.
4. Select (5) Auxiliary Serial Port Setup from the main menu of the terminal program.
Ensure the settings match those listed below:
------------------------------------------------
| Auxiliary Serial Port Setup |
| (7767VIPX8x2 1.0.0) |
------------------------------------------------
------------------------------------------------
Baud Rate: 115200
Data Bits: 8
Parity: None
Stop Bits: 2
------------------------------------------------
(1) Set baud rate
(2) Set number of data bits
(3) Set parity
(4) Set number of stop bits
(S) Save and Exit
(X) Exit
>
Figure 11-11: Auxiliary Serial Port Setup Menu
5. Select (4) Under Monitor Display Setup from the main menu to set up the display card for ASCII
protocol operation.
------------------------------------------------
| Under Monitor Display Setup |
| (7767VIPX8x2 1.0.0) |
------------------------------------------------
------------------------------------------------
Protocol: Philips ASCII
Input Type: serial
------------------------------------------------
(1) Set protocol
(S) Save and Exit
(X) Exit
>
Figure 11-12: Under Monitor Display Setup Menu
