VIP-X System Manual
VIP-X - 26 Revision 1.0
HD/SDI OUTPUT 1A/B & 2A/B: When the output resolution of the card is set to 720p, 1080i,
1080p, 625i, and 525i this BNC connector has 10-bit serial digital video signals
compatible with the SMPTE 424M, SMPTE 292M and SMPTE 259M-C standards.
When the output resolution of the card is set to other resolutions, this output will not be
active. Since the 7767VIPX-RP2 rear panel accommodates two VIP-X modules, the
rear plate has HD/SDI Outputs 1A and 2A for the first VIP-X module and HD/SDI
Outputs 1B and 2B for the second VIP-X module.
AUX IN A/B: Auxiliary serial data input.
AUX OUT A/B: Auxiliary serial data output.
5.2. GENLOCK REFERENCE
To lock/time the output of the VIP to house reference the genlock input should be used.
GENLOCK INPUT: The genlock input is applied to the 7700FR-D frame, which provides genlock
to all 7767VIPX modules installed in the frame. The genlock signal may be NTSC or
PAL colour black. The reference input type is auto detected. The genlock reference
input is terminated to 75 ohms.
5.3. DVI VIDEO CONNECTIONS
DVI-D OUTPUT: The VESA DVI-I connectors provide DVI-D outputs suitable for driving a
computer video monitor. The 7767VIPX-RP2 has two DVI-D outputs. The monitor
must be capable of scanning at the line and pixel rate of the video input standard that
is being used.
Since the 7767VIPX-RP2 rear panel accommodates two VIP-X modules, the rear plate
two has DVI-D connections for each VIP-X module. DVI-D 1A and 2A for the first VIP-
X module and DVI-D 1B and 2B for the second VIP-X module.
The following resolutions are supported by the VIP module at both 50Hz and 60Hz:
XGA (1024x768) SXGA (1280x1024) UXGA (1600x1200)
WXGA (1280x768) 720p (1280x720) 576p/625i(720x576)
480p/525i (720x480) WXGA Alt (1366x768) SXGA+(1400x1050)
WSXGA+(1680x1050) 1080p(1920x1080) WUXGA(1920x1200)
XGA (1024x768) SXGA (1280x1024) UXGA (1600x1200)
WXGA (1280x768) 720p (1280x720) 576p/625i(720x576)
Table 5-1: Supported Resolutions at 50Hz and 60Hz
Recommended maximum cable lengths:
• DVI digital max length = 3 meters, or 10 feet
• VGA analog max length = 5 meters, or 15 feet
