9.2. CONFIGURING THE MODULE USING THE MODULE SERIAL PORT
Through the card-edge’s serial port, and using the serial 7700 upgrade cable connected to a PC’s serial
port running HyperTerminal (or equivalent), the VIP module’s IP address, subnet, and SNMP TRAP
destination address are identified. The 7700 upgrade cable supplied with the 7700FR-D frame is a
multi-coloured ribbon cable with a six pin header socket on one end and a female 9 pin D connector on
the other end, (Evertz part number
WA-S76) which is normally in the vinyl pouch at the front of the
manual binder.
Configure the port settings of the terminal program as follows:
Baud
115200
Data bits
8
Parity
None
Stop bits
2
Flow Control
None
Once the card is powered-up, the HyperTerminal connection displays boot-up status information and
once complete, ends with the “Status Message” as shown below:
Initialization Completed - 7767VIP Running
Press the <ENTER> key to view the main Menu. In the Main Menu, the following options are present
for module configuration. Once changes have been completed and saved, the VIP module should be
power-cycled for the changes to take effect.
---------------------------------------------------------
| Main Menu |
| (7767VIPX8x2 1.0.0) |
---------------------------------------------------------
(1) Network Configuration
(2) Onboard Server Configuration
(3) SNMP Configuration
(4) Under Monitor Display Setup
(5) Auxiliary Serial Port Setup
(6) SNTP Source
(7) Network Audio Configuration
(8) Nielsen Configuration
(9) Engineering/Debug
(X) Exit
>
