On all menus, there is an extra selectable item: BACK. Selecting BACK will take the user to the
previous menu (the one that was used to get into the current menu). On the main menu, BACK will
take the user to the normal operating mode (indicated by the moving line on the card edge display).
Table 9-1 provides a brief description of the top level of the menu tree that appears when the user
enters the card edge menu system. Selecting this item will take the user down into the next menu level
to set the value of that parameter. The details of those parameters are described in section 9.1.1.
NET
Menu item for setting the devices IP address*
Note: After setting the IP address and saving, the card must be power cycled for
changes to take effect.
Table 9-1: Top Menu Structure
9.1.1. Configuring the Display
NET
BACK
IP
NMSK
GTWY
BCST
DHCP
SAVE
BACK: Option to navigate back up one level from the current menu position. This is
the factory default menu option.
IP: (NETWORK ADDRESS): Option for setting the IP address for the VIP module. All
4 octets must be set.
NOTE: After changing the IP address, navigate to the SAVE option in order to store
the IP address for the device, then power cycle the device for the address to take
effect.
NMSK (NETWORK MASK): Option for setting the net mask for the VIP module.
NOTE:
After changing the Netmask, navigate to the SAVE option in order to store
the setting for the device, then power cycle the device for the address to take effect.
GTWY (GATEWAY ADDRESS): Option for setting the gateway address for the VIP
module.
NOTE:
After changing the Gateway address, navigate to the SAVE option in order to
store the setting for the device, then power cycle the device for the address to take
effect.
BCST (BROADCAT ADDRESS): Option for setting the broadcast address for the VIP
module.
NOTE:
After changing the Broadcast address, navigate to the SAVE option in order
to store the setting for the device, then power cycle the device for the address to take
effect.
DHCP (DHCP ENABLE/DISABLE): Option for enabling or disabling DHCP for the VIP
module, normally set to disabled.
NOTE: After changing the DHCP, navigate to the SAVE option in order to store the
setting for the device, then power cycle the device for the address to take effect.
SAVE (SAVE NETWORK SETTINGS): Option for saving changes made to the above
options. The user is required to save only a single time for multiple changes to be
applied.
NOTE:
After saving, the VIP modules must be power cycled.
