6.2.5. Genlock Input
Type: NTSC/PAL colour black
Level: 1V p-p nominal
Connector: BNC via 7700FR-D (frame genlock)
6.2.6. General Purpose Interface I/O (GPI/GPO)
Number of Inputs: 4 (pins 10, 11, 12, 13)
Number of Outputs: 2 (pins 4, 9)
Type: GPI: 1 Opto-isolated, active low with internal pull-ups to +5V
GPO: 1 Relay closure to ground
Input Signal: Closure to ground
Connector: HD-15
6.2.7. Input/Output Serial Port
Number of Ports: 1 RS-232 (pins 6,7) or 1 RS-422 (pins 1,2,6,7)
Connector: HD-15
Baud Rate: Up to 1Mbaud
Format: Image Video, TSL
6.2.8. Ethernet
Network Type: Fast Ethernet 100 Base-TX 1EEE 802.3U standard for 100Mbps base band
CSMA/CD local area network
Connector: RJ-45 x2
6.2.9. Electrical
Voltage: +12V DC
Power: 75W
6.2.10. Physical
Number of Slots: 5 slots (single module occupies only ½ of total rear plate)
