VIP-X System Manual
Revision 1.0 VIP-X - 59
8. At the “FTP>” prompt type
hash to turn on the progress indicator during the ftp upload.
9. At the “FTP>” prompt type
quote site upgrade to put the unit in upgrade mode. A message
indicating that the user is in upgrade mode is displayed.
10. At the “FTP>” prompt type:
put “the name of the file.bin” to send the firmware to the unit.
(For example: put 7767VIP_1v0b310.bin)
11. If the application file is not local to where the user is performing the ftp, then include the path with
the name (For example: put c:\firmware\ 7767VIP_1v0b310.bin).
"
During this time it is mandatory that all power cycles of the unit be avoided. Figure
10-3 displays a successful FTP session.
12. A message indicating the successful connection to the module is displayed.
13. File transfer occurs in several seconds, and the DOS window displays the “FTP>” prompt again.
14. At the “FTP>” prompt type
quit to exit the FTP procedure.
