ITT Cannon DIN1.0/2.3 Connector details
The Cannon 75 _ 1.0/2.3 connector series are widely used in applications requiring a high density
solution and have become a standard in telecommunications in many parts of the world. Designed to
meet the requirements of DIN 47247 and CECC 22230, these connectors feature a push/pull coupling
mechanism to ensure mating integrity and a snap-on interface for ease of connection. Due to their
small size these connectors can be densely packed while providing significant space savings over other
75Ω connector products.
Connectors and Tooling are available from ITT Cannon or your local ITT Cannon distributor. Additional
information can be found at ITT Cannon’s website: www.ittcannon.com
under: products, RF75, 1.0/2.3
Electrical
Impedance
75 Ω nominal
Frequency Range
With 75 Ω connector on 75 Ω cable = 0 -2 GHz
Voltage Rating
At Sea Level = 250 Vrms
Insulation Resistance
1000 M Ω minimum
Contact Resistance
Inner contact = 6 m Ω typical maximum Outer
contact = 2.5 m Ω maximum
With 75 connector on 75 Ω cable and
F=1GHz
0.1 maximum
Mechanical
Withdrawal Force, inner female contact
0.2 N (0.04 lbs.) minimum
Withdrawal force, outer male contact
0.7 N (0.15 lbs.) minimum
Insertion force between: Jacks & plugs
10 N (2.24 lbs.) maximum
Withdrawal force between: Jacks & plugs
0.9 N (0.20 lbs.) minimum
Materials
Bodies and nuts: Brass
Inner male contact: Brass of Berylium Copper.
Inner and outer female contacts: Berylium Copper.
Insulators: PTFE or Thermoplastics
Crimp ferrules: Copper alloy
Finish / Plating:
Contact surfaces: Gold over Nickel.
Bodies and crimp ferrules: Nickel or Gold over
Nickel
Environmental
Temperature Rating
-40 degrees C to 85 degrees C
General
Connector Durability
500 matings minimum
Standards
CECC 22230, DIN 47297, RC9333 (T54 only)
