MAC/IP/UDP
Modify Frame Structure
Allows modifying the structure of the frame.
 Global Option
 Layer Mode sets the frame layer mode for all services (available
with EtherSAM for rates up to 10G WAN when the S-OAM check
box is cleared):
Mixed (default) allows configuring the frame layer per service: L2,
L3, or L4.
L2 Only configures all services to Layer 2 only (no IP, no MPLS).
 IP Version allows selecting IPv4 (default) or IPv6 that will be used
for both the interface and all streams/services.
 Framing
Note: The framing for EtherSAM in a NAT environment is limited to Ethernet II,
IPv4, and UDP.
 Frame Format (layer 2) allows selecting Ethernet II (default) or
802.3 SNAP as the frame format.
 Network Layer
1
(layer 3) sets the network traffic type:
IPv4 (default)/IPv6, or None.
 Transport Layer
1
is disabled when the Network Layer is None.
1. Not available with EtherSAM when Layer Mode is set to L2 Only .
Test Application Transport Layer
EtherSAM None, UDP (default), TCP
RFC 2544 UDP
EtherBERT UDP (default), TCP
Traffic Gen & Mon None, UDP (default), TCP
