Test Setup - Test Configurator, Timer, and System
MaxTester 163
Signal
Physical Interface - Electrical
Note: The following settings are available with electrical signal and their
availability depend on the signal itself and its mapping. For optical
interface, see Physical Interface - Optical on page 161.
LBO (Line Build Out): The LBO allows meeting the interface
requirements over the full range of cable lengths.
Line Coding
Signal LBO
DS1 Preamplification values: DSX-1 (0-133 ft)
a
, DSX-1 (133-266 ft), DSX-1 (266-399 ft),
DSX-1 (399-533 ft), DSX-1 (533-655 ft),
Cable simulation (CSU Emulation mode) values: CSU (0.0 dB), CSU (-7.5 dB), CSU (-15.0
dB), CSU (-22.5 dB).
a. Default value
DS3 0 to 225 ft range
a
, 225 to 450 ft range, and Cable Simulation 900 ft.
E1/E3/E4 Not available
STS-1e/STM-0e 0 to 225 ft range
a
, 225 to 450 ft range, and Cable Simulation 900 ft).
STS-3e/STM-1e 0 to 225 ft range.
Signal Line Coding
DS1 AMI and B8ZS
a
a. Default value.
DS3 B3ZS
E1 AMI and HDB3
a
E3 HDB3
E4 CMI
STS-1e/STM-0e B3ZS
STS-3e/STM-1e CMI
