Test Setup - Test Configurator, Timer, and System
164 MAX-800 Series
Signal
RX Termination
Power indicates the received signal level in dBdsx for DSn or dBm for
PDH and SONET/SDH.
Amplitude indicates the received signal amplitude as well as its MIN,
and MAX received values.
TX Frequency
Note: The following TX Frequency information applies to serial interface only,
refer to TX Frequency on page 105 for parallel interfaces.
TX Frequency (GHz) indicates the frequency (actual frequency +
Frequency offset) used for transmission.
Offset (ppm) check box, when selected (cleared by default), allows
setting the frequency offset that will be generated. Use the “+” or “-”
button to respectively increment or decrement the frequency offset
value based on the defined Increment/Decrement Size, or directly
type the frequency offset value in the field. Possible offsets are:
Signal Termination
DS1/E1 Ter m
a
, Mon, and Bridge.
a. Default value.
DS3/E3/E4/STS-1e/STM-0e/STS-3e/STM-1e Te r m
a
, and Mon
Interface Frequency Offset
a
Nominal Frequency
DS1 ±140 ppm 1544000 bit/s
E1 ± 70 ppm 2048000 bit/s
