Test Setup - Test Configurator, Timer, and System
MaxTester 165
Signal
Note: Frequency offset is not available when Through mode is selected.
Step Size (ppm) allows setting the increment/decrement value (from
0.1 to the maximum offset) that will be used when changing the
frequency offset with the “+” or “-” button.
RX Frequency
Note: The following RX Frequency information applies to serial interface only,
refer to RX Frequency on page 107 for parallel interfaces.
Frequency (GHz) indicates the frequency of the input signal.
Offset (ppm) indicates the frequency offset between the standard rate
specification and the rate at the input signal.
E3 ± 50 ppm 34368000 bit/s
DS3 44736000 bit/s
STS-1e/STM-0e 51840000 bit/s
E4 139264000 bit/s
STS-3e/STM-1e 155520000 bit/s
OC-1/STM-0 ± 50 ppm 51840000 bit/s
OC-3/STM-1 155520000 bit/s
OC-12/STM-4 622080000 bit/s
OC-48/STM-16 2488320000 bit/s
OC-192/STM-64 9953280000 bit/s
OTU1 ± 50 ppm 2666057143 bit/s
OTU2 ± 50 ppm (Framed)
± 120 ppm (Unframed)
10709225316 bit/s
a. The frequency offset range is guaranteed for a source signal at 0 ppm. In the event
that the source signal already has an offset, then the output signal may exhibit an
offset larger than the range specified.
Interface Frequency Offset
a
Nominal Frequency
