Test Setup - Test Configurator, Timer, and System
82 MAX-800 Series
BERT and Unframed BERT
OTL
b
LOF, OOF, LOL, LOR, OOR, Inv. Marker, FAS
FEC FEC CORR, FEC UNCORR
OTUk AIS, LOF, OOF, LOM, OOM, BDI, IAE, BIAE, BIP-8, BEI, FAS, MFAS
ODUk AIS, OCI, LCK, BDI, BIP-8, BEI, FSF, BSF, FSD, BSD
OPUk AIS, CSF, PLM
c
, LOOMFI
d
, OOMFI
d
, OMFI
d
BER
e
Pattern Loss, Bit Error (default)
a. Not available with QSFP transceivers.
b. The service disruption time measurement is available per lane for OTL defects at the exception of LOL
which is global for all lanes. Refer to OTL-SDT on page 264 for results per lanes.
c. Available when the PLM check box is selected (refer to page 111 for more information).
d. Available with OPU4 only.
e. Available when the No Pattern Analysis (Live) check box (see page 78) is cleared.
Layer Signal Defect
Interface OTN/SONET/SDH LOS
DSn LOS, BPV, EXZ
PDH LOS, CV
OTUk OTN AIS, BDI, BEI, BIAE, BIP-8, FAS, IAE, LOF, LOM, MFAS, OOF, OOM
ODUk OTN AIS, OCI, LCK, BDI, BIP-8, BEI, FSF, BSF, FSD, BSD
OPUk OTN AIS, CSF
Section/RS SONET/SDH LOF-S/RS-LOF, B1
Line/MS SONET/SDH AIS-L/MS-AIS, RDI-L/MS-RDI, REI-L/MS-REI, B2
STS/AU Path SONET/SDH AIS-P/AU-AIS, LOP-P/AU-LOP, RDI-P/HP-RDI, REI-P/HP-REI, B3,
UNEQ-P/HP-UNEQ, PDI-P (SONET)
VT/TU Path SONET/SDH AIS-V/TU-AIS, LOP-V/TU-LOP, RDI-V/TU-RDI, REI-V/LP-REI, BIP-2,
UNEQ-V/LP-UNEQ
DS1 DSn AIS, OOF, RAI, Framing Bit, CRC-6
DS3 DSn AIS, OOF, Idle, RDI, F-Bit, C-Bit, P-Bit, FEBE
E1 PDH AIS, CRC-4, E-Bit, LOMF, TS16 AIS, LOF, FAS, RAI, RAI MF
Layer Defect
