Extreme Networks ExtremeSwitching 5320 Series User Manual

Power cord wall plug Refer to Power Cord Requirements for AC-Powered
Switches and AC Power Supplies on page 108
Efciency Minimum efciency: 85% at maximum power output
115VAC
150 W AC Power Supply
The 150 W AC power supply is a xed internal unit for model 5320-24T-24S-4XE-XT.
Voltage input range
90-132/198-264 47 to 63Hz
Nominal input ratings 1.8A max at 115Vrms
Maximum inrush current 120A at Max 230VAC / 50Hz at 25C
Output 12V, 12.5A @150W
Power supply input socket and
cord
IEC/EN 60320-1/C14 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered
Switches and AC Power Supplies on page 108
Efciency Minimum 87% at maximum power output
250 W AC Power Supply
The 250 W AC power supply is a xed internal unit for model 5320-16P-4XE.
Voltage input range
90-132/198-264 47 to 63Hz
Nominal input ratings 3.8A max at 90VAC at Full 250W load
Maximum inrush current 60A at Max 230VAC / 50Hz at 25C
Output 12V, 4.58A max, 54V, 3.61A max, 250W
Power supply input socket and
cord
IEC/EN 60320-1/C16 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered
Switches and AC Power Supplies on page 108
Efciency Minimum efciency: 90% at maximum power output
115VAC
550 W AC Power Supply
The 550 W AC power supply is a xed internal unit for model 5320-24P-8XE.
Voltage input range
90-132/180-264 47 to 63Hz
Nominal input ratings 8.5A max at 90VAC at Full 550 W load
Maximum inrush current 30A at Max 115VAC / 60Hz at 40C
Output 12V, 12.5A max, 54V, 7.4A max 550 W
Power supply input socket and
cord
IEC/EN 60320-1/C16 AC input receptacles
Power Supply Specications Technical Specications
102 ExtremeSwitching 5320 Series Hardware Installation Guide

Extreme Networks ExtremeSwitching 5320 Series Specifications

General

Brand	Extreme Networks
Model	ExtremeSwitching 5320 Series
Category	Switch
Language	English
