4. Add the port to use as the management port to the virtual router using the

following command:

configure vr vr-name add port port-number

configure vr vr-mymgmt add port 12

5. Add the port to use as the management port to the VLAN using the following

command:

configure vlan-name add port port-number

configure myvlan add port 12

6. Congure the IP address and subnet mask length using the following command:

configure vlan-name ipaddress ipaddress/subnet-mask

configure myvlan ipaddress 10.69.8.100/24

7. Congure the default gateway (you must specify VR-Mgmt for the management

port and VLAN mgmt) using the following command:

configure vlan-name iproute add default ipaddress vr vr-name

configure iproute add default 10.69.8.1 vr vr-mymgmt

8. Enter save to save your conguration changes so that they will be in effect after the

next system reboot

Results

The conguration is saved to the conguration database of the switch.

Change the Switch OS via the Bootloader Menu

Before You Begin

Note

FabricEngine does not support models 5320-24T-4X-XT and 5320-24T-24S-4XE-

XT.

Onboard your switch with ExtremeCloud™. Log in or create your XIQ administrator

account in order to select your switch operating system with XIQ at https://

extremecloudiq.com.

About This Task

SwitchEngine is the default operating system for the 5320 Series. You can change

the switch OS from the Bootloader menu on initial activation only by completing the

following steps:

Procedure

1. Using a terminal emulator such as PuTTY or TeraTerm, connect to the switch using

the serial port connection.

Be sure that your serial connection is set properly:

• Baud rate: Baud rate: 115200

• Data bits: 8

• Stop bit: 1

Change the Switch OS via the Bootloader Menu Activate and Verify the Switch

84 ExtremeSwitching 5320 Series Hardware Installation Guide
