Port LEDs in Default (SYS) Mode
In the default System mode, SPD is OFF, and the port status displays behavior for link,
trafc, and PoE as described in the following table:
Note
PoE is not supported on models 5320-24T-4X-XT and 5320-24T-24S-4XE-XT.
Color/State Meaning
Steady green Link is OK
Steady amber Link is OK; no trafc
Blinking green Link is OK and transmitting packets
Blinking amber Link is OK and transmitting packets
Alternating amber and green Port has a power fault
Off Port has no link, or is disabled
Port LEDs in SPD Mode
The port LEDs enter the SPD display mode when the Mode button is pressed the rst
time, indicated by the SPD LED. SPD mode is used to help determine the operational
speed of a port.
Color and blink pattern indicate speeds, as referenced by the following table.
Note
Models 5320-24T-4X-XT and 5320-24T-24S-4XE-XT do not support 2.5 Gbps, 5
Gbps, and 25 Gbps speeds.
Color/State Speed
Steady green 10Mbps
Blinking green 100Mbps
Solid amber 1000Mbps
Slow blinking amber 2.5Gbps
Fast blinking amber 5Gbps
Slow blinking green 10Gbps
Fast blinking green 25Gbps
Port LEDs in Default (SYS) Mode Monitor the Switch
92 ExtremeSwitching 5320 Series Hardware Installation Guide
