Safety Considerations for Installation
Read the information in this chapter thoroughly before you attempt to install or
remove an Extreme Networks switch.
Ensure that proper ESD (electrostatic discharge) controls are in use before switch
maintenance is performed. This includes but is not limited to wrist straps that are
grounded to the switch housing and earth grounds.
Warning
Connect the chassis ground wire before you connect any power cables.
Disconnect the ground wire after you disconnect all power cables.
Take care to load the equipment rack so that it is not top-heavy. Start installing
equipment at the bottom of the rack and work up.
Do not cover vents that would restrict airow.
Note
See Safety and Regulatory Information on page 111 for additional safety
information regulatory compliance certications.
What You Will Need for the Installation
Ensure that you have followed the guidance in Site Preparation on page 27, and ensure
that you have the appropriate people and tools on hand.
Installing Extreme Networks switches is easiest when there are two people to
maneuver the switch and attach mounting hardware.
Provide enough space in front of and behind the switch so that you can service it easily.
Ensure that a minimum of 122 cm (48 in) in front of the rack and 76 cm (30 in) behind
the rack.
If your switch has internal power supplies, make sure they have the same airow
direction as the fans in the switch.
Check the
Quick Reference Guide
for your switch model to see what hardware is
provided in the switch packaging.
You need the following additional tools and equipment. These are not provided with
your switch:
• Screwdriver for securing the rack mounting screws.
• #2 Phillips magnetic screwdriver to attach bracket screws that are provided with the
switch.
• ESD-preventive wrist strap for installing optional ports at the back of the switch.
Mount the Device
The 5320 Series provides multiple options for mounting or installing the switch.
Safety Considerations for Installation Install Your Switch
60 ExtremeSwitching 5320 Series Hardware Installation Guide
