SMP 111 • Front Panel Operation 22
Bit Rate (Video)
Recording and streaming encodes have independent video bit rate settings. Video (VID)
bit rate sets a target video bit rate from 200 kbps to 10000 kbps (default 5000 kbps).
Bit Rate (Audio)
Recording and streaming encodes have the same audio bit rate settings. Audio bit rate
allows the user to select an audio bit rate in kbps from the following selections:
• 80 • 96 • 128
• 192 (default) • 256 • 320
Preview HDMI output
NOTE: When the selected recording resolution is under 720 lines (for example, if the
recording encoder is set as 848x480 or 512x288) the HDMI preview output is set to
1280x720, with the video content centered in the 720p window.
Input format
Audio Select
The Audio input format can be:
• Analog audio — for analog audio from the rear panel captive screw connections
• Digital audio — embedded HDMI audio
• Analog + Digital audio — mixed audio (default)
The SMP111 accepts 2CH PCM (stereo) audio embedded in the HDMI input signal.
Audio level
Each audio input channel can be adjusted from -18 dB to +24dB. The default value is
0dB. The selected input is displayed in the first line.
Film detection (interlaced input formats only)
Film detection is automatically enabled when an interlaced input format is selected. Film
detection supports 2:2 and 3:2 detection. The processing maximizes image detail and
sharpness for interlaced sources that originated from film. Film detection is valid for any
interlaced input type. The SMP111 de-interlaces 1080i inputs.
Film detection mode cannot be disabled and has no user adjustments.
