SMP 111 • Front Panel Operation 19
Preset
#
Preset
Name
Resolution Video
Bit Rate
(kbps)
Frame
Rate
(fps)
Audio
Bit Rate
(kbps)
Bit Rate
Control
GOP
Length
H.264
Profile
H.264
Level
1 1080p High 1920x1080 8000 30 320 VBR 30 High 4.1
2 1080p Low 1920x1080 6000 15 128 CVBR 30 Main 3.2
*3 720p High 1280x720 5000 30 192 VBR 30 High 3.1
4 720p Low 1280x720 3000 15 128 CVBR 30 Main 3.1
5 480p High 848x480 2500 30 128 VBR 30 High 3.1
6 480p Low 848x480 1500 15 96 CVBR 30 Main 3.1
7 VGA High 1280x1024 3500 30 128 VBR 30 High 4.1
8 VGA Low 1024x768 2500 15 128 VBR 30 High 3.1
9-16 User Defined
NOTES:
• * Audio settings are determined by the encoding recording. Audio for streaming monitoring is not re-
encoded. Therefore, by default, the recording uses encoder preset 3, and the audio bit rate is 192 kbps.
Default audio sample rate is 48 kHz. When RTMP Push streaming is selected, the audio sample rate is
changes to 44.1 kHz automatically.
• Default record mode is video and audio.
• The predefined encoder presets can be modified by the user. If necessary, a factory reset returns all
changes to the above table values.
Streaming and Recording
The SMP111 supports simultaneous recording and streaming with one stream output.
Each can have a different resolution, frame rate, and bit rate. The default is Pull, unicast
RTP/UDP. Streaming and recording functions can be enabled and disabled via the internal
web pages and SIS commands (see Encoder Settings and Metadata on page49 or
Streaming Presets on page83).
NOTE: The stream preview on the Web-based UI is video only (no audio).
Streaming can be on (enabled) or off. When streaming is enabled, the stream method,
Stream protocol, and multicast IP or destination IP submenus are available.
The appropriate submenus are displayed depending on the Streaming method selection.
Streaming Presets
Streaming presets allow the user to quickly switch between various streaming options.
There are 16 encoder presets that can be saved or recalled from the internal web page
(Configuration > Encoding & Metadata > Metadata and Recording Profiles).
Streaming presets save the following parameters:
STREAMING PRESETS
Preset name Multicast IP/destination (for Multicast only)
Streaming method and protocol QoS (for Push streaming only)
Stream port SAP setting (for push streaming only)
MTU RTMP publish URL (for RTMP push only)
TTL Advanced section of RTMP, such as the
RTMP port, Username, and Password (for
RTMP push only)
RTSP over HTTP port (for Pull streaming only)
