SMP 111 • Remote Communication and Control 75
Command and Response Tables
Command
Function
SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Information requests
NOTE: An asterisk (*) after the version number indicates the currently running version. Question marks (?.??) indicate that only factory
firmware is loaded. A caret (^) indicates the firmware version that should be running, but a Mode1 reset (see SMP111 Rear Panel Reset
on page 14) was executed and the default factory firmware is running. An exclamation point (!) indicates corrupted firmware. These apply
to 0Q-4Q.
Firmware version
Q or 1Q
X4%] Firmware version to 2 decimal
places (1.00).
Firmware and build
version
*Q/q
X4%] Firmware version to 2 decimal
places plus build number to 4
decimal places (1.12.1234).
Verbose version info
0Q
Sum of 2Q-3Q-4Q
] Show bootstrap, factory‑
installed, and updated firmware
version.
Bootstrap Version
2Q
X4% ]
The bootstrap firmware is
not user replaceable but you
may need this information for
troubleshooting.
Factory Firmware
Version
3Q
X4%
plus Web ver.‑desc‑UL date/
time
]
Factory installed firmware is not
user replaceable. This firmware
is the version the SMP reverts to
after a mode 1 reset.
Example:
3Q
1.00.0000-b2325(1.81LX-SMP111 -Sat, 01 Nov 2014 20:10
UTC)
]
Updated firmware
version
4Q
X4%
plus Web ver.‑desc‑UL date/
time
]
Use this command to find
out which version of firmware
has been uploaded into the
SMP111.
Example:
1.00.0004-b2635*(1.81LX-SMP111 -Sun, 02 Nov 2014 00:12
UTC)
]
Query part number
N
60-1594-01
]
Query model name
1I
Example: SMP•111
]
Query model
description
2I
Streaming•Media•Processor
]
Query system memory
usage
3I
#Bytes used out of #KBytes
]
Query location
5I
<Location>
]
Query internal drive
free space
15I
internal*xx.xxGB
]
Query USB drive free
space
16I
<drive volume>*xx.xxMB,<drive volume>*xx.xxMB
]
View stream resolution
and frame rate
31I
<Stream resolution>*<Frame rate>
]
Example:
1280x720*30
View record resolution
and frame rate
33I
<Stream resolution>*<Frame rate>
]
Example:
1280x720*30
Query selected
storage (single
recording)
37I
<Selected Storage Destination>
]
Query selected
storage (secondary
recording)
37I
<internal*Selected USB Storage>
]
NOTES: X4% = Firmware version number
