SMP 111 • Remote Communication and Control 76
Command and Response Tables (continued)
NOTES: X* = Executive mode 0 = Off; 1 = Complete lockout (no front panel control);
X4$ = Configuration type 0 = IP config (ip.cfg); 2 = Box specific parameters (box.cfg)
X4^ = Unit name Unit name is a text string of up to 63 characters drawn from the alphabet (A‑Z), digits (0‑9),
and the minus sign/hyphen (‑). The first character must be an alpha character.
The last character must not be a minus.
X6# = Default name Combination of model name and last three pairs of MAC address
(Example: SMP‑111‑07‑8C‑EC)
X6* = Verbose/Response mode 0 = clear/none (Default for Telnet connections)
1 = verbose mode (Default for USB and RS‑232 host control)
2 = tagged responses for queries
3 = verbose mode and tagged responses for queries
NOTE: If tagged responses is enabled, all read commands return the data, the same as setting
the value does (Example: command: E
CV} Response: Vrb3
])
Command
Function
SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
View number of
connected users
10I
N
] Number of users.
View system
processor usage
11I
NN
] Returns a percentage of total.
View system
processor idle
12I
NN
] Returns a percentage of total.
View eth0 link status 13I
Current link state (up/down)* speed in MB (10/100/1000)*
mode (full/half)
]
View file transfer
config
38I
Example: \\Network_Storage\Folder, cifs
]
Clear active alarms E
CALRM
}
Alrm C
] Clear all active alarms.
View active alarms
39I
<name:alarm_name>,<level:alarm_level>...>
]
If no active alarms: None active]
Set unit name
E X4^
CN
}
Ipn
X4^
]
Set unit name to
default
E
•
CN
}
Ipn
X6#]
View unit name
E
CN
} X4^
]
View Telnet
connections
E
CC
}
n
]
Icc
n
]
n = number of active IP
connections.
Verbose mode 2/3.
Set verbose mode E X6*
CV
}
Vrb
X6*]
View verbose mode
E
CV
} X6*]
Query RCP
50I
<model
name>*<part
number>*<rmware>]
View information of
the attached wallplate
or AAP
INF50*
<model
name>*<part
number>*<rmware>]
Backup/Restore
Save configuration E
1*
X4$
XF
}
Cfg1*
X4$ ] Save configuration to file
location (/nortxe‑backup).
Restore configuration E
0*
X4$
XF
}
Cfg0*
X4$ ] Load configuration from file
location (/nortxe‑backup).
Front panel lock (executive mode)
Enable
1X
Exe1
] Disable all front panel controls.
Disable
0X
Exe0
] Enable all front panel controls.
View status
X
X*]
Exe
X*]
Show executive mode status.
Verbose mode 2/3.
