SMP 111 • Remote Communication and Control 74
X5)
= IP address in dotted decimal notation
(xxx.xxx.xxx.xxx)
Default IP address: 192.168.254.254
(no padding)
Default gateway IP address: 0.0.0.0
Default DNS server IP address: 0.0.0.0
X5!
= Subnet mask
Default: 25.255.0.0 (no padding)
X5@
= Hardware MAC address
(00-05-A6-NN-NN-NN)
X5#
= Time in 10s of milliseconds to wait for
characters coming into a serial port
before terminating (min=0, max=32767
and default=10=100 ms). The response
is returned with leading zeros.
X5$
= Time in 10s of milliseconds to wait for
characters coming into a serial port
before terminating (min=0, max=32767
and default=2=20 ms). The response is
returned with leading zeros.
X5%
= Parameter to set either Length of
message to receive or Delimiter value.
L=#=byte count (min=0, max=32767:
default=0L=0 byte count).
D = decimal value for ASCII character.
(min=0, max=00255. Default=00000L).
Value is placed prior to parameter: 3
byte length = 3L and ASCII 0A delimiter
is 10D. The parameter is case sensitive,
must use capital D or capital L. The
response is returned with leading zeros.
X5^
= Priority status for receiving timeouts:
0 = use Send data string command
parameters (if they exist [Default]).
1 = use Configure receive
timeout command parameters
instead.
X5&
= RS‑232 baud rate (9600 [Default], 19200,
38400, 57600, 115200)
X5*
= RS‑232 parity: single letter:
Odd, Even, None (Default), Mark, Space.
X5(
= RS‑232 data bits: 7, 8 (Default)
X6)
= RS‑232 stop bits: 1 (Default), 2
X6!
= Password: maximum length 12
characters. All alpha‑numeric characters
permitted except /,\,|,"space", and "*".
X6@
= Port timeout in tens of seconds (zero
padded. Default: 00030 = 300 seconds)
X6#
=
Default name: combination of model
name and last three pairs of MAC
address (example SMP-111-07-8C-EC)
X6$
= SNMP contact name text, up to
64 characters
(Default="Not Specified").
X6%
= SNMP location, up to 64 characters
(Default="Not Specified").
X6^
= SNMP public community string, up to 64
characters (Default="public").
X6&
= SNMP private community string, up to 64
characters (Default="private")
NOTE: SNMP names and community
strings can be up to 64 alphanumeric
characters including hyphens,
underscores and periods.
X6*
= Verbose mode
0 = clear/none (Default for Telnet
connections)
1 = verbose mode (Default for USB and
RS‑232 host control)
2 = tagged responses for queries
3 = verbose mode and tagged
responses for queries
