SMP 111 • Remote Communication and Control 73
X2@
=
Audio delay — 0 to 999 milliseconds
X2#
= Front panel audio level indication
-1500 to 0 (in .01 dBfs step)
X2$
= Output frame rate
1 = 30
2 = 25
3 = 24
4 = 15
5 = 12.5
6 = 12
7 = 10
8 = 5
X2%
=
Output mode
1 = Video and audio
3 = Audio only
4 = Video/audio + audio only
X2^
=
Bit rate control and type
0 = VBR
1 = CVBR
2 = CBR
X2&
= Video bit rate target — 2000 to 10000
Default = 5000
X2*
= Audio input gain in 0.1 dB steps
(‑180 to 240 = ‑18.0 to +24.0 dB)
X2(
=
GOP length — 1 to 30 (Default = 30)
X3)
= Audio format
0 = Disable audio
1 = Analog
2 = PLCM 2 CH (Default)
X3!
= Presets — 1 to 16
(Two digit response — 0 padding)
X3@
=
Audio bit rate — 80, 96, 128,
192 (Default), 256, 320 kbps
X3#
= Mute status
0 = Unmuted
1 = Muted
X3$
=
EDID numbers — 1 to 38
X3%
= Overscan
0 = 0 % (Default)
1 = 2.5 %
2 = 5.0 %
X3^
= Encode profile
0 = Base
1 = Main
2 = High
X3&
= Audio output
1 = HDMI only
2 = Analog only
3 = HDMI and Analog
X3*
= Record mode
0 = Off
1 = Single
2 = Secondary
X3(
=
EDID user slots — 1 to 3
X4)
= Streaming method
0 = Disabled
1 = RTMP
2 = RTSP
3 = Push RTP
X4!
= RTMP URL (String)
X4@
= Json string of recording profile
parameters — Example:
{"id":1,"name":"RECORD PROFILE 01",
"mode":"audio and video",
"contributor":"Contributor1",
"coverage":"Coverage1",
"presenter":"Presentor1",
"description":"Description1",
"format":"Format1",
"language":"Language1",
"publisher":"Publisher1",
"course_id":"Course1",
"copyright":"Copyright1",
"source":"Source1",
"subject":"Subject1",
"title":"Title1",
"license":"License1"}
X4#
= Recording destination
0 = Auto
1 = Internal
2 = Front USB
3 = Rear USB
4 = RCP USB
11 = Internal and auto
12 = Internal and Front USB
13 = Internal and Rear USB
14 = Internal and RCP USB
X4$
= Configuration type
0 ‑ IP Config (ip.cfg)
2 ‑ Box specific parameters (box.cfg)
X4%
= Firmware version number
X4^
= Device name (63 characters, max)
Must comply with internet host name
standards.
X4&
= Day, date, and time
(Day,•MM•DD•YY‑HH:MM:SS)
X4*
= Time zone acronym (2 to 6 letters)
X4(
= Greenwich Mean TIme (GMT) offset
value: ‑12:00 to 14:00. Represents hours
and minutes (HH:MM) offset from GMT
including the time zone name.
