Chapter 6 Fastening Operation
PAGE 6-47
D-No.035 System Option 3 Standard setting: 000000
Option 3 function setting
xxxxx1: Restrict cycle start after Total Accept (0: OFF ./ 1: ON).
Set to “1to prohibit a restart after a TOTAL-OK
In order to restart the fastening operation, turn ON any of the following input signals.
RESET
STOP
PROGRAM
Note: Even if the PLC I/O input signal [BATCH OK RESET] is turned "ON", the fastening
operation will not re-start.
(Even if the spindle judgment is REJECT (NG), the next fastening start will not be
performed before Controller firmware version 1.300)
xxxx1xInitial display of Fastening Results (0:D-No.00 / 1:D-No.37)
When the controller is powered up, set the initial display preference of the fastening result
mode.
0: D-No.00 Displays Peak Torque (only)
1: D-No.37 Displays Peak torque (upper part) / Final angle (lower part)
xxx1xxDisplay Stop Status (0:During Stop Input / 1:At Startup after STOP)
Changes the STOP status (controller) display condition
• 0: Displays STOP while the PLC I / O input signal [STOP] is "ON"
• 1:Displays while the PLC I / O input signal [STOP] is "ON" and the rising edge of the PLC
I/O input signal [START (REVERSE)] ("OFF" → "ON")
xx1xxxCW / CCW Change Select (0:Ignore Tool CW/CCW switch / 1: Use Tool CW/CCW Switch)
When using a PLC START input signal, selects to ignore the tools CW/CCW switch or use
the CW/CCW switch for direction control
0: Ignores the tool CW/CCW switch position and starts the fastening (directed by the
programmed parameter direction)
1: Starts the fastening in the direction the tool CW/CCW switch is currently set in
x1xxxxTB2-2_CF Warning signal output (0:Disable / 1:Enable)
Setup to use the PLC I/O output signal [CF WARNING] of I0 Terminal Block TB2-2.
0: Disable signal will not be output (do not connect)
1: Signal is output when the CF card remaining capacity is less than 200 MB on the
controller with the CF card option installed.
1xxxxxSpecial Function 1(0:OFF / 1:ON)
Not Used Set to “0”
D-No.036 Gearhead Option Standard setting: 0, Setting range: 0 ~ 2
0: Standard head 1: Regular tube nut (bottom socket) 2: Inverted tube nut (top socket)
D-No.037 Start (starting) Switch Level Standard setting: 10, Setting range: 0 ~ 255
Please set 10.
D-No.038 High-speed Starting Switch Level Standard setting: 40, Setting range: 0 ~ 255
Please set 40.
*Set to 10 for ‘push to start’ tool (D) type.
D-No.039 Reverse Switch Level Standard setting: 10, Setting range: 0 ~ 255
Please set 10.
D-No.040~049 For Adjustment by the Manufacturer
Not used.
