Chapter 6 Fastening Operation
PAGE 6-48
System Parameters - Connected Tool Settings
D-No.100 Connected Tool No.
Assigned Tool No. corresponding to the connected tool model. Please refer to “Tool Models.”
D-No.101 Connected Tool Information
The maximum torque and motor capacity of D-No. 100 “Connected Tool No.”
D-No.102 Tool CAL Torque Decimal Point
The decimal point position of the torque value of D-No. 103 “Tool CAL Torque”.
D-No.103 Tool CAL Torque [N•m]
The CAL torque of the tool is displayed
D-No.104 Tool CAL Voltage [V]
The CAL voltage of the tool is displayed
D-No.105 Tool ZERO Voltage [V]
The ZERO voltage of the tool is displayed
D-No.106 Tool Internal Gear Ratio (×100)
The value obtained by multiplying the gear ratio of the tool by 100
D-No.107 Tool Serial No. (upper 3 digits) D-No.108 Tool Serial No. (lower 4 digits)
The serial No. of the tool is displayed
D-No.109 Tool Rotation Direction
The rotation direction of the tool is indicated. (CW: 0, CCW: 1)
D-No.110 Tool Order No. (upper 2 digits) D-No.111 Tool Order No. (lower 5 digits)
The order No. of the tool is displayed
D-No.112 Tool Cycle Count (×1 million)
D-No.113 Tool Cycle Count (×1)
Indicates the number of times (count) of fastening cycles performed by the connected tool.
* When the count is less than 1 million times, [------] is indicated for D-No. 112.
D-No.114 Tool Maximum Current [A]
This indicates the maximum current of the tool.
