FEC Handheld Nutrunner HFC3000 - Page 121

Chapter 6 Fastening Operation
PAGE 6-51
(“o” indicates which fieldbus uses which SYS D-No)
SYS.300
CC-Link
DeviceNet
PROFIBUS
DP-V1
PROFINET
IO
EtherNet/IP
SYS.303
○
○
○
-
-
SYS.304
○
○
-
-
-
SYS.305
○
-
-
-
-
SYS.306
○
-
-
-
-
SYS.307
○
○
○
○
○
SYS.308
○
○
○
○
○
SYS.309
○
○
○
○
○
SYS.310
○
○
○
○
○
SYS.311
○
○
○
○
○
SYS.312
-
-
-
○
○
SYS.313
-
-
-
○
○
SYS.314
-
-
-
○
○
SYS.315
-
-
-
○
○
SYS.316
-
-
-
○
○
SYS.317
-
-
-
○
○
D-No.303 Station No. (Node Address) (CC-Link, DeviceNet, PROFIBUSDP-V1 only)
The programmed station No. (node address) of the installed fieldbus is displayed
Fieldbus Type
CC-Link
DeviceNet
PROFIBUSDP-V1
1～64
0～63
0～125
D-No.304 Communication Speed Setting range: 0 ~ 4 (CC-Link, DeviceNet)
The programmed communication speed of the installed fieldbus is displayed
Fieldbus Type
System Parameter D-No.304
0
1
2
3
4
CC-Link
156kbps
625kbps
2.5Mbps
5Mbps
10Mbps
DeviceNet
125kbps
250kbps
500kbps
-
-
D-No.305 Occupied Stations Setting range: 1 ~ 4 (CC-Link only)
The CCLINK programmed number of occupied stations is displayed
D-No.306 Extended Cyclic Setting Setting range: 1, 2, 4, 8 (CC-Link Only)
The CCLINK programmed extended cyclic setting is displayed
D-No.307 I/O Setting Byte Length “PLC ￫ HFC3000” [byte]
(besides standard IO and expansion IO)
The programmed I/O setting byte length for “PLC ￫ HFC3000” of the installed fieldbus is displayed
D-No.308 I/O Setting Byte Length “HFC3000 ￫ PLC” [byte]
(besides standard IO and expansion IO)
The programmed I/O setting byte length for “HFC3000 ￫ PLC” of the fieldbus is displayed
