6-6-2 Fastening Parameters (Items in gray cells are not displayed)
Item
PAR No.
D-No.
Contents
Torque
Method
Angle
Method
Fastening
Settings
P.01～
P.64
000
Fastening Method
0
1
001
Fastening Steps
○
○
002
Fastening Option
○
○
003
Judgment Item 1
○
○
004
Judgment Item 2
○
○
005
After Fastening Operation
○
○
006
Interrupt Operation During Fastening
○
○
Torque
[N・m]
P.01～
P.64
100
Calibration Torque
○
○
101
Peak Torque Low Limit
○
○
102
Peak Torque High Limit
○
○
103
Standard Torque
○
104
Ramp Down Start Torque
○
○
105
1st Torque
○
○
107
Snug Torque
○
○
108
Snug Torque High Limit
○
○
109
2nd Torque
○
○
110
Reverse Torque High Limit
○
○
111
Torque Inhibit Limit
○
○
112
Rate 1 Start Torque
○
○
113
Rate 1 End Torque
○
○
114
Rate 2 (Differential Angle) Start Torque
○
○
115
Rate 2 (Differential Angle) End Torque
○
○
116
Rate 3 Start Torque
○
○
117
Rate 3 End Torque
○
○
118
Final Torque Low Limit
○
○
119
Final Torque High Limit
○
○
120
Option
△
△
121
1 Pulse Reverse Torque High Limit
○
○
Angle
[deg]
P.01～
P.64
200
Final Angle Low Limit
○
○
201
Final Angle High Limit
○
○
202
Standard Angle
○
203
1st Angle
○
○
204
2nd Angle
○
○
205
Torque Inhibit Angle
○
○
206
Differential + Angle
○
○
207
Differential – Angle
○
○
208
Option
△
△
209
Correction Angle
△
△
211
Option
△
△
△: Unavailable.
