Chapter 6 Fastening Operation
PAGE 6-54
System Parameters – Remote Touch panel Information
D-No. 500 IP Address (upper 6 digits) D-No. 501 IP Address (lower 6 digits)
Setting range: 0 ~ 255
The IP address of the remote touch panel connected to the controller is displayed.
D-No.502 Touch Panel Function / Language Setup Standard setting:0 Setting range: 0～4
Allows disable / enable of the remote touch panel function and the language setting
●0: Disables the remote touch panel function
● 1-4: Enables and sets the language according to the chart below
Touch Panel Function Disable
D-No.503 TCPIP Port Number Standard setting:1024 Setting range: 1024～65535
The TCPIP Port Number of the touch panel connected in the controller is displayed.
SYS.504 Touch Panel Number of Retries Standard setting:0 Setting range:0～9
Allows the setting of automatic communication retries if the fastening result is experiencing
communication errors. Sets the number of automatic retires in the case of communication errors.
(A fastening START can not be performed during a retry)
･After changing the settings of D-Nos. 500 ～ 504, power must be cycled on the
controller for the settings to activate.
･Changes can only be made when the controller is in Program mode (“ProG”indicated
in the upper display) The controller must be put back to RUN mode (“ProG” no longer
displayed in upper display) before powering down or the change will not be stored to
memory.
