The fastening judgment is not performed regardless of the values of the high and
low limit set values when the settings of fastening parameters D-No. 003
“Judgment Item 1” and D-No. 004 “Judgment Item 2” are set to “0” (off).
D-No. 003 Judgment Item 1 Default setting: 111101
*****1: Peak Torque Check Cannot be Disabled
･ Judge peak torque during the fastening operation is within the range of the high and low limit values
****1*: Final Torque Check
･ Judge final torque at the end of the fastening operation is within the high and low limit ranges
(Normally used only when ANGLE Control is the control method)
***1**: Final Angle Check Cannot be Disabled
･ Judge final angle at the end of the fastening operation is within the high and low limit ranges
The starting point of angle measurement is D-No. 107 [Snug Torque].
**1***: Rate 1 Check
･ Judge the 1
st
torque rate (slope) from D-No. 112 [Rate 1 Start Torque] to D-No. 113 [Rate 1 End
Torque] is within the high and low limit ranges when D- No. 113 [Rate 1 End Torque] is attained
*1****: Rate 2 Check
･ Judge the 2
nd
torque rate (slope) from D-No. 114 [Rate 2 Start Torque] to D-No. 115 [Rate 2 End
Torque] is within the high and low limit ranges when D- No. 115 [Rate 2 End Torque] is attained
1*****: Rate 3 Check
･ Judge the 3
rd
torque rate (slope) from D-No. 116 [Rate 3 Start Torque] to D-No. 117 [Rate 3 End
Torque] is within the high and low limit ranges when D- No. 117 [Rate 3 End Torque] is attained
