Chapter 6 Fastening Operation
PAGE 6-60
D-No. 004 Judgment Item 2 Default setting: 000001
*****1: Timeout Check Cannot be Disabled.
･ Judges whether the fastening has taken place within the set high/low time limits. 1
st
Time is from
the start of fastening to D-No. 105 [1st Torque] or D-No. 205 [1st Angle]. 2nd Time is from D-No.
105 [1st Torque] or D-No. 205 [1st Angle] to the end of fastening.
****1*: Revolution Check
･ Judges the number of rundown revolutions from the start to end of fastening is within the high and
low limit ranges
***1**: Differential Angle Check
･ Judges the differential angle, calculated from the rate 2 from D-No.114 [Rate 2 Start Torque] to
D-No. 115 [Rate 2 End Torque] and the final torque, is within the high and low limit ranges
**1***: Snug Torque Check
･ Judges the torque value is below the Snug high limit when D-No. 107 [Snug Torque] is detected.
*1****: Break Away Torque Check
･ Judges the torque value is below the Reverse Torque high limit during reverse operation.
1*****: Torque Inhibit Check
･ Judges the torque value is below the Torque Inhibit limit during operation at D-No. 205 [Torque
Inhibit Angle].
