D-No. 400 Initial Speed [rpm]
Setting range: Minimum tool speed to maximum tool speed
Setting of Initial speed can be used as a slower rpm to aid in socket / fastener engagement, reduce
initial engagement shock, etc., at the start of fastening. Operation of initial speed is executed during
D-No. 310 [Initial Time].
D-No. 401 Freerun Speed [rpm]
Setting range: Minimum tool speed to maximum tool speed
Sets the ‘high-speed’ rotation speed after the end of D-No. 310 [Initial Time]. Rotation at the freerun
speed is performed for D-No. 500 [Freerun Revolutions] or until D-No. 104 [Ramp Down Start Torque]
is attained.
D-No.402 1
ST
Speed [rpm]
Setting Range：Minimum tool speed to maximum tool speed
Set the speed between D-No.401 [Freerun Speed] and D-No.403 [2
ND
Speed].
The system rotates at the 1
ST
Speed until D-No.105 [1
ST
Torque] is detected from D-No.104 [Slow
Down Start Torque] or until D-No.203 [1
ST
Angle] is detected from D-No.104 [Ramp Down Start
Torque].
*If D-No.105 [1
ST
Torque] or D-No.203 [1
ST
Angle] is reached during the D-No.401 [Freerun Speed],
1
ST
Speed will be switched over to D-No.403 [2
ND
Speed].
D-No.403 2
ND
Speed [rpm]
Setting Range：Minimum tool speed to maximum tool speed
Sets the speed after 1
st
Torque is reached.
The speed used after D-No.105 [1
ST
Torque] or D-No.203 [1
ST
Angle] is reached. (in a 1 or 2-Step
fastening, this is the slower speed used for final torque process)
* Fastening accuracy is improved the slower the 2
ND
Speed is set.
D-No.404 3
RD
Speed [rpm]
Setting Range：Minimum tool speed to maximum tool speed
Sets the speed after 2
nd
Torque is reached
This is the speed after D-No.106 [2
ND
Torque] or D-No.204 [2
ND
Angle] is reached.
* Fastening accuracy is improved the slower the 3rd Speed is set.
Set the same value as D-No.403 [2
ND
Speed], if a different 3
RD
Speed is not used.
