Chapter 6 Fastening Operation
PAGE 6-71
D-No.405 Reverse 1 Speed [rpm]
Setting range: Minimum tool speed to maximum tool speed
Sets the speed during reverse operation.
The speed at which reverse rotation is performed while the REV. pushbutton on the controller is
pushed, When the Reverse-FWD tool switch is rotated to the reverse position or the Reverse I/O
signal is turned on.
This is also the speed used in D-No. 002 [Fastening Option]: “Reverse before Fastening.”
D-No.406 Reverse Speed between 1-2 Step [rpm]
Setting range: Minimum tool speed to maximum tool speed
Sets the speed during reverse operation between 1
st
and 2
nd
Step if used.
This is the speed used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 1-2 Steps
ON.”
D-No.407 Reverse Speed between 2-3 Step [rpm]
Setting range: Minimum tool rotation speed to maximum tool rotation speed
Sets the speed during reverse operation between 2nd and 3rd Step if used.
This is the speed used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 2-3 Steps
ON.”
D-No.410 1 Pulse Reverse Speed [rpm]
Setting range: Minimum tool rotation speed to maximum tool rotation speed
The speed used during D-No. 005 [After Fastening Operation]: “1 Pulse Reverse.”
