Chapter 4 Installation and Wiring
PAGE 4-12
BATCH OK RESET: BATCH COUNTER RESET SIGNAL PIN No.: TB3-5
After performing fastening for the set number of times (when using the Batch count feature), the cycle
count value is cleared automatically at the start of the next fastening process. The count will also be
cleared with this signal.
If the WORK SELECT has been input to TB1 or changed on the front panel of the controller, the
current cycle count value is cleared by input of this reset signal.
BANK SELECT: OUTPUT SIGNAL BANK SELECT SIGNAL PIN No.: TB1-12
The signal definition of the eight output signals are changed by switching ON/OFF the BANK SELECT
signal.
UNUSED PIN No.: TB3-6,
This is not used.
WORK SELECT 0 ~ 4: Work Select Signals PIN No.: TB1-7 ~ 11
WORK SELECT 5: Work Select Signals PIN No.: TB3-9
A parameter set can be selected ‘on the fly’ by using the Work SELECT inputs (Up to 64). They can be
selected by a combination of the WORK SELECT 0 ~ WORK SELECT 5 input signals (selection for up
to 64 parameters (Work Select bit 5) can only be used from a Fieldbus interface or from the front
display panel). (Work Select Bit 5 firmware ver. 1.310 or later)
