FEC Handheld Nutrunner HFC3000 - Page 49

Chapter 4 Installation and Wiring
PAGE 4-13
(Continued from previous page)
WORK SELECT
5
PIN No.:TB3-9
WORK SELECT
4
PIN No.: TB1-11
WORK SELECT
3
PIN No.: TB1-10
WORK SELECT
2
PIN No.: TB1-9
WORK SELECT
1
PIN No.: TB1-8
WORK SELECT
0
PIN No.: TB1-7
WORK
No.
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
33
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
34
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
35
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
ON
36
ON
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
37
ON
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
ON
38
ON
OFF(OPEN)
OFF(OPEN)
ON
ON
OFF(OPEN)
39
ON
OFF(OPEN)
OFF(OPEN)
ON
ON
ON
40
ON
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
41
ON
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
ON
42
ON
OFF(OPEN)
ON
OFF(OPEN)
ON
OFF(OPEN)
43
ON
OFF(OPEN)
ON
OFF(OPEN)
ON
ON
44
ON
OFF(OPEN)
ON
ON
OFF(OPEN)
OFF(OPEN)
45
ON
OFF(OPEN)
ON
ON
OFF(OPEN)
ON
46
ON
OFF(OPEN)
ON
ON
ON
OFF(OPEN)
47
ON
OFF(OPEN)
ON
ON
ON
ON
48
ON
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
49
ON
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
50
ON
ON
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
51
ON
ON
OFF(OPEN)
OFF(OPEN)
ON
ON
52
ON
ON
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
53
ON
ON
OFF(OPEN)
ON
OFF(OPEN)
ON
54
ON
ON
OFF(OPEN)
ON
ON
OFF(OPEN)
55
ON
ON
OFF(OPEN)
ON
ON
ON
56
ON
ON
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
57
ON
ON
ON
OFF(OPEN)
OFF(OPEN)
ON
58
ON
ON
ON
OFF(OPEN)
ON
OFF(OPEN)
59
ON
ON
ON
OFF(OPEN)
ON
ON
60
ON
ON
ON
ON
OFF(OPEN)
OFF(OPEN)
61
ON
ON
ON
ON
OFF(OPEN)
ON
62
ON
ON
ON
ON
ON
OFF(OPEN)
63
ON
ON
ON
ON
ON
ON
64
ID SELECT ENABLE：ID SELECT ENABLE SIGNAL PIN No.: TB3-10
With System parameter: SYS D - No 411 "External Input Select" set to "ID Input", the ID selection
from the “ID Data INPUT” becomes enable by setting this signal to “ON”.
The WORK number can then be selected by the input ID Data (sent through RS232 or Fieldbus
Message) (ASCII character · maximum 32 characters)
If the SYS D-No 411 external input selection is set to "Input ID" and this signal is "OFF", select the
WORK number from the PLC I/O.
External input Select is setup using the HFC UserConsole "Graphic style parameter setup” selection
and selecting the (System parameter) from the pulldown menu.
This signal can be used with Controller software version V1.301 or later.
