5 Conversion and maintenance
Festo – P.BE-MPA-E N – 1309f – English 119
12
234
1 Multi-pin plug connection plate
2 Guide pins
3 Seal
4 Pneumatic sub-base
Fig. 5.14 Mounting the multi-pin plug connection plate
3. Push the multi-pin plug connection plate together with th e pneumatic sub-bases. Make sure that
the seal and the components are correctly positioned.
