2Overview
Festo – P.BE-MPA-E N – 1309f – English 23
1
23421
4
5
1 Exhaust plate (3/5) or flat plate silencer
2 Valve or blanking plates
3 Vertical pressure shut-o ff plate
4 Pressure regulator plate
5 Electronic module with LEDs
Fig. 2.9 Components of the MPA-S valve terminal with electric multi-pin or AS interface, 2nd level
