2Overview
22 Festo – P.BE-MPA-EN – 1309f – English
The MPA-S v alve terminal with electric multi-pin or AS interface consists of the following pneumatic
components:
1
23
454
1 Right end plate
2 Pneumatic air supply plate
3 Inscription label with support
4 Manifold block with working lines and
electrical interlinking module
5 Seal (optionally separating se al for forming
pressure zones)
Fig. 2.8 Components of the MPA-S valve terminal with electric multi-pin or AS interface, 1st level
