3 Mounting and installation
Festo – P.BE-MPA-E N – 1309f – English 71
Line Connection
code (ISO
5599)
Connection
size
(ISO 228)
Connection
1)
Compressed air or vacuum (1) G¼” Fitting in electrical interface or in the
pneumatic air supply plate
Pilot air (external pilot air
supply)
(12/14) M7 Fitting in electrical interface or in the
multi-pin plug connection plate
Ducted exhaust air from
the valves
(3/5) QS10 Fitting in exhaust plate
2)
Ducted exhaust air from
the pilot control
(82/84) M7 Fitting in the air supply plate
2)
Airorvacuum (2) or (4) MPA1: M7
MPA2: Gx”
Fitting in the sub-base
Connection for external
pressure
P1 M7 Fitting in pressure sensor plate type
VMPA -FB-PS-P1
Pressure input (1) G¼” Fitting in the sub-base of the proportional
pressure regulator
Pressure output (2) G¼”
Exhaust air of the
VPPM-…TA
(3) G¼”
1) Dependent on your order, the MPA-S valve terminal may already be equipped with QS fittings.
2) Only for valve terminal MPA-S with exhaust plate or air supply plate
Tab. 3.9 Assignment of the connections
