215
The structure Ø must be fixed in the
points indicated using a total of 6
M10x1.25 screws and 4 M12 screws.
MAX LOAD ON BALL: 100/120 kg
depending on the payload (see the
“Weights” table in the “Technical
Specifications” chapter).
WARNING
182)
The ABS with which the vehicle may
be equipped will not control the braking
system of the trailer. Particular caution is
required on slippery roads.
183)
Never modify the braking system
of the vehicle to control the trailer brake.
The trailer braking system must be fully
independent from the hydraulic system of
the vehicle.
184)
After fitting, screw holes must be
sealed to prevent exhaust gas infiltrations.
