Fiat Ducato 2021 - Bonnet; Electric Windows

67
the ceiling and the rear footwell vents,
varying the temperature.
WARNING If the compressor on the
main climate control system control is
turned on (operation of button E), even
if the additional climate control system
fan is in position 0, the 1st speed will
automatically be activated to prevent
ice formation, with possible damage to
the component.
ELECTRIC WINDOWS
Switches fig. 110 on the inner armrest
of the driver's door control the following
with the ignition key in the MAR
position:
(A): left front window
opening/closing;
(B): right front window
opening/closing.
110 F1A0762
Continuous automatic operation
The driver's side front window allows
continuous automatic operation in both
directions: opening and closing. The
passenger-side window only allows
continuous automatic operation for
opening.
Keep one of the buttons pressed for
longer than half a second to operate
the automatic continuous window
operation function. The window stops
when it reaches the end of travel
position, or when the button is pressed
again.
WARNING With the ignition key in
the STOP position or extracted, the
electric windows remain activated for
about 3 minutes and are deactivated
immediately when one of the doors is
opened.
Front passenger side door
A dedicated switch for operating the
window is located on the inner armrest
of the passenger side front door.
40)
WARNING
40) Improper use of the electric windows
can be dangerous. Before and during
operation, always check that nobody is
exposed to the risk of being injured either
directly by the moving window or through
objects getting caught or hit by it. When
leaving the vehicle, always remove the key
from the ignition switch to avoid the risk of
injury to anyone remaining in the vehicle
due to accidental operation of the electric
windows.
BONNET
OPENING
Proceed as follows:
open the driver's door to gain access
to the bonnet release;
pull the lever fig. 111 in the direction
indicated by the arrow;
lift lever (A) fig. 112 as shown in the
figure;
lift the bonnet and, at the same time,
release the supporting rod fig. 113 from
its locking device (D), then insert the
end of the rod (C) fig. 114 into housing
(E) in the bonnet.
WARNING Before opening the bonnet,
check that windscreen wiper arms are
not lifted from the windscreen.
